Anchor Point
Parapet Anchor
PARAPET ANCHOR – SKU: GGPA034 The Parapet Anchor is designed to provide a secure anchorage point on parapets and facades for various elevated work applications. Unlike traditional screw-bolt anchors that may damage the base structure, this system preserves the appearance of the parapet and facade wh…
Pricing: trade prices are shown to registered customers. Log in to the customer portal, or ask us for a quote with certification documents.
Specifications
| Standard | Designed to EN 795:2012 Type A + CEN/TS 16415 — certificate on request |
| EN requirement | Static test 12 kN (18 kN if any load-bearing part is non-metallic), +1 kN per additional user (CEN/TS 16415) |
PARAPET ANCHOR – SKU: GGPA034
The Parapet Anchor is designed to provide a secure anchorage point on parapets
and facades for various elevated work applications. Unlike traditional screw-bolt anchors
that may damage the base structure, this system preserves the appearance of the
parapet and facade while ensuring safe fall protection.
FEATURES
• Provides safe anchorage on parapets and facades
• Non-invasive design that protects the base structure
• Soft inner flange lining prevents surface damage
• Adjustable flanges to suit parapet widths from 60 mm to 360 mm
• Designed to limit user swing to less than 30° during suspended work
• Designed for single-user use
WIDTH RANGE
• 60 mm to 360 mm
MATERIAL
• Alloy Steel with black ED coating
WEIGHT
• 9.0 kg ± 0.01 kg
STRENGTH
• Minimum Breaking Strength: 23 kN
