Description
Product Overview
-
System Type: Modified epoxy resin, styrene-free, safe, and non-toxic.
-
Application: Suitable for structural reinforcement, equipment installation, and fixing curtain wall brackets.
-
Versatility: Ideal for anchoring on side or top surfaces due to excellent thixotropic properties.
-
Operation: Injection-type system that eliminates the need for manual mixing, shortening construction progress.
Technical Specifications and Performance
-
Mixture Ratio (Weight): 3:1.
-
Viscosity of Mixture: 18-22 pa-s.
-
Density after Curing: 1.5 +/- 0.10 g/cm3.
-
Compressive Strength: 126.6 Mpa.
-
Flexural Strength: 76.7 Mpa (No rupture-like damage).
-
Split Tensile Strength: 8.75 Mpa.
-
Steel-Steel Anti-Shear Strength: 18.2 Mpa.
-
Non-volatile Matter Content: 99.1%.
Curing Schedule The operable and curing times are highly dependent on the ambient temperature
-
-5 Degrees C: Operable 60 min | Curing 72 h.
-
10 Degrees C: Operable 30 min | Curing 24 h.
-
20 Degrees C: Operable 15 min | Curing 16 h.
-
30 Degrees C or higher: Operable 20 min | Curing 8 h.
Anchor Installation Parameters
Typical data for threaded bar (M8-M16) installation:
-
M8: Drill 12mm | Depth 80mm-120mm | Volume 6.03-9.04 ML.
-
M10: Drill 14mm | Depth 100mm-150mm | Volume 10.26-15.08 ML.
-
M12: Drill 16mm | Depth 120mm-180mm | Volume 16.09-24.12 ML.
-
M16: Drill 22mm | Depth 160mm-240mm | Volume 40.52-60.79 ML.
Key Advantages
-
Stability: Low moisture sensitivity for long-term load stability in humid environments.
-
Resistance: High resistance to acid, alkali, and aging.
-
Safety: Styrene-free, non-toxic, and anti-shock with no expansion stress fixation.
-
Effectiveness: High adhesion strength equivalent to pre-embedded reinforcements.
Storage and Packaging
-
Standard Packing: 585ml cartridges (20 pcs per carton).
-
Shelf Life: At least 12 months from the date of manufacture when stored correctly.
-
Storage Conditions: Store in original, upright packaging in cool conditions (+50F to +77F) and out of direct sunlight.
