Groxx Standing Seam Clamp | SSC005 Seam-Grip Anchor Plate
The Groxx SSC005 Standing Seam Clamp is a precision-engineered anchorage interface designed to provide a secure, non-penetrative mounting point on industrial metal roofs. Developed specifically for hidden-fix and standing seam profiles, this clamp is the foundation of the Groxx roof-safety ecosystem, adapting to varying seam geometries while guaranteeing a rock-solid, vibration-resistant connection without compromising the roof’s integrity.
Key Features & Performance
-
Non-Penetrative Seam Grip: Designed to attach directly to the vertical standing seams using a high-torque clamping mechanism. This approach preserves the roof’s watertight seal, thermal performance, and original structural warranty.
-
Precision M8 Integrated Mounting: The clamp features two pre-fabricated, precision-machined M8 threaded holes on both the top and front-side faces. This dual-face configuration provides unparalleled flexibility for mounting I-brackets, H-frames, safety anchors, and lifeline intermediates.
-
Streamlined Universal Design: Its low-profile design minimizes wind loading and visual impact, while its internal clearance accommodates diverse seam shapes without interference.
-
Turnkey Assembly (Image Details): The total system length is a precise 100mm, offering an ideal balance of compact size and substantial clamping surface. Mounting holes are precisely spaced to fit a standard 60mm ±0.5mm center-to-center configuration.
Dimensions & Tolerances
-
Component Length: 100 mm
-
Base Footprint (Width): 32.9 mm
-
Overall Height: 36.0 mm
-
Internal Seam Clearance: 18 mm (Top) to 16 mm (Taper) wide, and 28 mm in height.
-
Front Mounting Hole Position: 20mm ±0.5mm (from edge).
-
Bottom Mounting Hole Positions: 50mm ±0.5mm and 40mm ±0.5mm (from edge).
-
Finish & Tolerance: All dimensions are subject to tight engineering tolerances to ensure consistent performance.
Material Specifications
Manufacturing Standards & The Groxx Advantage
The G011 Standing Seam Clamp is manufactured under stringent quality controls, adhering to global ISO standards for metal fabrication. Its precise design guarantees that fall protection systems are anchored correctly from the ground up. Furthermore, to verify authenticity and ensure traceability, all clamps are precision laser-engraved with the official Groxx logo on both the front and rear faces. This branding signifies a commitment to engineering excellence and life-saving reliability.
Note: This clamp is designed for use as a primary interface. It is crucial to verify that the target roof sheet and seam profile meet the specific load requirements of the final safety system before installation. Consult with a qualified engineer for multi-user lifeline configurations.
