V - Line Upper End Bracket
The Groxx GRXRLS10 is a specialized structural component designed to secure rigid rail systems to a variety of substrates. It functions as a critical stabilization point that controls the span, stiffness, and allowable deflection of the rail, ensuring the system operates within its engineered safety parameters.
Structural Guidance: Engineered to maintain the alignment of the rigid rail, providing consistent guidance for the traveler shuttle during horizontal or vertical movement.
System Stiffness Control: By managing the spacing between supports, the GRXRLS10 controls the overall stiffness of the rail system, which is essential for minimizing dynamic oscillations during a fall event.
Non-Load-Bearing Classification: This component is classified as a non-load-bearing anchor, meaning it does not directly withstand primary fall impact forces but provides the necessary structural support for multi-span installations.
Versatile Design: The depth of the thread is customizable based on the final installation object, allowing for precise integration with different building structures.
Multi-Span Support: Designed to facilitate the installation of long-distance rigid rail systems by providing intermediate stabilization points.
Support Spacing: Proper installation requires that support spacing be determined based on specific system design parameters, including the total span, the number of simultaneous users, and the allowable deflection limits.
Concrete Interface: For mounting to concrete slabs, this component can be used in conjunction with the GRX851 Chemical Anchor system to ensure a high-strength, permanent bond.
The GRXRLS10 meets the fixing and stabilization requirements of international rigid rail safety standards:
EN 795:2012 Type D: Certified for use within rigid rail anchor systems (Rated for 1 user).
CEN/TS 16415:2013: Tested and compliant for multi-user applications (up to 3 users) when incorporated into a complete certified system.
Validity Period: Offered with a 10-year validity period for both 304 Stainless Steel and Aluminum variants, supported by mandatory annual inspections.
The GRXRLS10 provides the essential structural backbone for any rigid rail installation. Its low-profile design and dual-material construction allow it to blend seamlessly into industrial or architectural environments while maintaining the strict stiffness requirements necessary for high-performance fall protection.
